Datavideo TLM-700K 7-Inch 4K LCD Look-back Monitor

Datavideo TLM-700K 7-Inch 4K LCD Look-back Monitor

DATTLM-700K

$199.00 USD
$199.00 USD
Sale Sold out
Datavideo TLM-700K 7-Inch 4K LCD Look-back Monitor

Datavideo TLM-700K is a full featured 7-inch 4K LCD Look-back monitor that will fit anyones budget. TLM-700K supports 4K down to SD at 1920x1200 panel resolution. Simple to set-up, simple to use, with simple HDMI input and loop out configuration.

TLM-700K Features:

  • Supports 4K/3G/HD/SD/ 1920x1200 panel resolution
  • Simple Input and Output configuration
  • 1x HDMI Input and Loop Out
  • Peaking Fast and Accurate
  • Red/Green/Blue peaking profile helps to instantly determine if the focus is accurate
  • Enable to preview shooting, recording, playback in real-time
  • False Color Display, enable to judge if camera exposure needs adjustment
  • Check Field. For easy color recognition and correction.
  • Zoom In, 1.5x, 2x, 3x, 4x for clearly viewing shooting details
  • Flexible with Dual Power Supply Modes, adapter or battery
  • Foldable Light Hood
  • Screen Flip Function. Vertical, Horizontal, Vertical and Horizontal
  • Safety Marker and Aspect Marker

    • TLM-700K Specifications:

  • Screen: 7" TFT LCD
  • Chassis: Camera Mount
  • Resolution: 1920x1200
  • Viewing Angle: (H) +85/-85°, (V) +85/-85°
  • Luminance/Contrast: 450cd/m², 1000:1
  • Video Inputs: 1x HDMI (1.4b), HDCP 1.4
  • Loop Through: 1x HDMI (1.4b)
  • Supported Input Resolutions:
    4096x2160p(24Hz)
    3840x2160p(23/24/25/29/30Hz)
    2048x1080p(50/59.94/60Hz
    1080p(23.98/24/25/29.97/30/50/59.94/60Hz)
    1080i(50/59.94/60Hz)
    720p(23.98/24/25/29.97/30/50/59.94/60Hz)
    576i(50Hz), 576p(50Hz)
    480i(59.94/60Hz), 480p(59.94/60Hz)
  • Aspect Ratio: 16:9
  • Audio In/Out:
    Embedded Audio (48KHz sampling)
    Analog Stereo (Phone Jack)
    Speaker x1 (2W)
  • Special Features: Focus assist (peaking), False Color, Histogram, Exposure, Pixel to Pixel Zoom, Underscan, Check Field (blue-only mode, monochrome mode)
  • Dimension (LxWxH): 182 x 129 x 37 mm
  • Weight: 0.3 kg
  • Operating Temp. Range: 0~40 °C
  • Power: DC 12V, 12W

    • Whats in the Box:

  • 1 x TLM-700K product
  • 1 x AD Switch DC 12V
  • 1 x Folding sun shade cover
  • 1 x HDMI A/C cable
  • 1 x Battery plate
  • 1 x Hot shoe mount
    •
